Investigation of ultrasonic flowmeter error in distorted flow using two-peaks Salami functions

Simple item page
dc.citation.epage151
dc.citation.issue2
dc.citation.spage144
dc.contributor.affiliationНаціональний університет “Львівська політехніка”
dc.contributor.affiliationLviv Polytechnic National University
dc.contributor.authorМатіко, Федір
dc.contributor.authorРоман, Віталій
dc.contributor.authorМатіко, Галина
dc.contributor.authorЯлінський, Дмитро
dc.contributor.authorMatiko, Fedir
dc.contributor.authorRoman, Vitalii
dc.contributor.authorMatiko, Halyna
dc.contributor.authorYalinskyi, Dmytro
dc.coverage.placenameЛьвів
dc.coverage.placenameLviv
dc.date.accessioned2023-09-19T07:59:57Z
dc.date.available2023-09-19T07:59:57Z
dc.date.created2021-06-01
dc.date.issued2021-06-01
dc.description.abstractНаведено результати досліджень додаткової похибки ультразвукових витратомірів (УЗВ), спричиненої спотворенням профілю швидкості потоку. Координати розташування хордових акустичних каналів (АК) обчислено для 1–6 АК за допомогою різних числових методів інтегрування: Гаусса (Гаусса – Лежандра, Гаусса – Якобі), Чебишева (рівновіддалене розміщення АК), методу Westinghouse, методу OWICS (Optimal Weighted Integration for Circular Sections). Це дало можливість реалізувати рівняння витрати багатоканального УЗВ та оцінити додаткову похибку УЗВ за різного розміщення АК. Значення середньої швидкості потоку вздовж кожного АК визначено розрахунково на основі профілю швидкості потоку в поперечному перерізі ВТ. Для обчислення профілю швидкості спотвореного потоку, сформованого типовими місцевими опорами, використано чотири двоядерні функції швидкості Саламі. За результатами дослідження додаткової похибки УЗВ в умовах спотвореного потоку розроблено рекомендації щодо вибору кількості акустичних каналів УЗВ та застосування методів визначення координат розташування акустичних каналів.
dc.description.abstractResults of investigating the additional error of ultrasonic flowmeters caused by the distortion of the flow are presented in the article. The location coordinates of acoustic paths were calculated for their number from 1 to 6 according to the different numerical integrating methods: Gauss (Gauss-Legendre, Gauss-Jacobi), Chebyshev (equidistant location of acoustic paths), Westinghouse method, method of OWICS (Optimal Weighted Integration for Circular Sections). This made it possible to realize the flowrate equation for multi-path ultrasonic flowmeters and to determine their additional error for different location of the acoustic paths. The average flow velocity along each path is calculated based on the flow velocity profile in the pipe cross section. Four two-peak Salami functions of velocity are used to calculate the velocity profile of the distorted flow caused by typical local resistances. According to the research results the recommendations were developed for choosing the number of the acoustic paths of the ultrasonic flowmeters and for using the methods for determining the location coordinates of the acoustic paths.
dc.format.extent144-151
dc.format.pages8
dc.identifier.citationInvestigation of ultrasonic flowmeter error in distorted flow using two-peaks Salami functions / Fedir Matiko, Vitalii Roman, Halyna Matiko, Dmytro Yalinskyi // Energy Engineering and Control Systems. — Lviv : Lviv Politechnic Publishing House, 2021. — Vol 7. — No 2. — P. 144–151.
dc.identifier.citationenInvestigation of ultrasonic flowmeter error in distorted flow using two-peaks Salami functions / Fedir Matiko, Vitalii Roman, Halyna Matiko, Dmytro Yalinskyi // Energy Engineering and Control Systems. — Lviv : Lviv Politechnic Publishing House, 2021. — Vol 7. — No 2. — P. 144–151.
dc.identifier.urihttps://ena.lpnu.ua/handle/ntb/60146
dc.language.isoen
dc.publisherВидавництво Львівської політехніки
dc.publisherLviv Politechnic Publishing House
dc.relation.ispartofEnergy Engineering and Control Systems, 2 (7), 2021
